Name: YTM IK220 24V 27A Single Slot Alternator 0120489410 ALT4041 0986032190 0986032191 0120489793 for FIAT 4786920 Replacement Parts
Brand: Yute Motor(Guangzhou) Mechanical parts Co., Ltd.
SKU: IK220
Price: 177.00 USD
Availability: InStock

Home Products Electric Alternator Motor

YTM IK220 24V 27A Single Slot Alternator 0120489410 ALT4041 0986032190 0986032191 0120489793 for FIAT 4786920 Replacement Parts

Product Details:

Place of Origin:	China
Brand Name:	YUTE
Model Number:	IK220

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Negotiable
Packaging Details:	YTM /Neutrail /Customized
Delivery Time:	15-30 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union,
Supply Ability:	50000 Pcs/ Month

Contact Now

Detailed Product Description

Appliion:

FIAT

Warranty:

18 Months

Condition:

100% New

SPECS:

24V/27A

Highlight:

24V 27A single slot alternator

FIAT alternator replacement parts

YTM IK220 electric alternator motor

YTM IK220 24V 27A Single Slot Alternator

This high-performance 24V 27A single slot alternator is engineered to exact OEM specifications, ensuring perfect compatibility and reliable performance as a direct replacement for FIAT 4786920 and numerous other applications.

Premium Construction & Materials

Grease: German imported lubricating oil for gear box and drive gear, meeting military high/low temperature standards (-50° to 230°)
Bearings: Domestic first-line brand deep groove ball bearings and INA needle roller bearings imported from the United States
Copper Components: Stator coil bare copper wire and armature pure copper enameled wire meeting international OEM standards with 230° high temperature resistance
Steel Construction: Stator casing from fine drawing seamless steel tube, drive gear using 20# steel cold chamber forging process
Aluminum: All aluminum components manufactured from international standard ADC12 material
One-way Gear: Songer system standard quality for reliable operation
Relay: Taiwan Songer imported with chip protection to prevent burning
Generator Core: Silicon steel sheet construction for effective magnetic field performance
Enameled Wire: All F grade 180° high temperature wire from major domestic manufacturers
Insulation Material: 350° high temperature resistance with inner fiber and outer rubber hose construction
Rotor: Claw pole and rigid ring design with magnetic steel addition for improved low-speed performance
Electronic Components: Supplied by four major domestic manufacturers ensuring consistent quality

Quality Assurance

Every alternator undergoes comprehensive testing including 100% production testing, warehouse testing, and factory testing according to OEM standard "DV" testing equipment protocols.

Cross-Reference Part Numbers

Manufacturer	Part Numbers
Bosch	0120489410, 0120489412, 0120489413, 0120489414, 0120489612, 0120489638, 0120489639, 0120489792, 0120489793, 0120489794, 0120489795, 0120489796, 0986031340, 0986031341, 0986032181, 0986032190, 0986032191
FIAT	4152610, 4220356, 4220357, 4223787, 4474902, 4715786, 4717871, 4721890, 4722724, 4738563, 4738569, 4738570, 4738571, 4738772, 4738775, 4786913, 4786914, 4786915, 4786916, 4786917, 4786918, 4786919, 4786920, 4803546, 4808268, 4808519, 4808520, 4808521, 4808522, 4808523, 4808524, 4808525, 4808526, 4808528, 4839558, 5990966, 77050550, 88206020
Magneti Marelli	063320025010, 63304000, 63304001, 63304020, 63304087, 63304420, 63304430, 63304440, 63306000, 63306050, 63306060, 63306070, 63306079, 63306089, 63306300, 63306301, 63306302, 63306320, 63306350, 63306360, 63306369, 63306370, 63306379, 63306380, 63306389, 63306399, 63306500, 63306520, 63308300, 63308310, 63308320, 63308330, 63308340, 63308350, 63308360, 63308370, 63308380, 63308389, 63308399, 63320025, 63320057, 63320060, 63320114, 63320118, 63321045, 63321046, 63321047, 63321048, 63321049, 63321050, 63321052, 63321055, 63321063, 63321115, 63321158, 63321161, 63321162, 63321163, 63321168, 63321181
Other Manufacturers	Cargo: 111142, 112109 \| CAS: CAL21601GS, CAL30600AS, CAL30600GS \| DAF: 1516529R \| Delco: 19025057, 90009960, 91309960, DRA1340 \| Denso: DAN604 \| EF: 10890 \| ELMOT: AA12528V30A, AA125E28V30A, AA125R14V30A, AA125R28V30A, AA125R28V35A \| HC-PARTS: CA212IR \| HELLA: 8EL725640001 \| Iskra: 11201055, 11201075, AAG1110, AAK1110, AAK1209 \| Iveco: 2997074, 4808269, 61146532, 98417209 \| KRAUF: ALE0212DD, ALE0212LP, ALE0212NW, ALE0212UX, ALE9212UX \| LUCAS: LRA839 \| MAHLE: MG369, MG516 \| Motorherz: ALB0212RB, ALE0212WA, ALE212WA \| Motorola: 9AR3952, 9AR3952G \| Messmer: 210298 \| Prestolite: 860141 \| Unipoint: ALT4041 \| Valeo: 2940753, 436416, 510391, 523070, 9AR3952G \| WAI: 1-3396-25W \| ZAUFER: 301N22532Z

Product Images

Manufacturer Profile

Yute Motor (Guangdong) Mechanical Parts Co., Ltd.

Established in 2008, Yute Motor specializes in the production of motor starters and alternators. With over 20,000 square meters of production facilities equipped with advanced equipment including high-precision CNC machining centers, automatic rotor spot welding machines, and modern automatic production lines, the company achieves an annual output of more than 200,000 units.

After 14 years of dedicated development, Yute Motor has become a pioneer in the construction machinery industry, with products certified to IS09001:2000, QS-9000, and ISO/TS16949 standards. The company's motor series have reached international advanced levels, with sales of construction machinery motors for excavators and heavy trucks consistently leading the market.
